6.9 Axes and spindles
6-83
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Once you have defined the drive type (VSA, SLM, HSA), you must then select
the associated power section.
This can be defined by:
– Entering the power section code directly (e.g. from Table 6-9)
– Selecting from the power section list (MLFB numbers) stored on the con-
trol using the “Pow.sect.sel...” vertical soft key, selecting the power sec-
tion using the cursor keys, then press the “OK” soft key to confirm and
then automatically returning to the configuration screen.
Requirement: The cursor must be on the same line as the
desired slot.
Table 6-14 Allocating the drive/power section/power section code
ÁÁÁ
Drive type
ÁÁÁÁÁÁÁÁÁÁ
Amperage
ÁÁ
Power
section
ÁÁ
Code
MSD
3 / 3 / 3 A
8 A
01
MSD
5 / 5 / 8 A
15 A
02
MSD
8 / 10 / 16 A
25 A
04
MSD
24 / 32 / 32 A
50 A
06
MSD
30 / 40 / 51 A
80 A
07
MSD
45 / 60 / 76 A
108 A
0D
MSD
45 / 60 / 76 A
120 A
08
MSD
60 / 80 / 102 A
160 A
09
MSD
85 / 110 / 127 A
200 A
0A
MSD
120 / 150 / 193 A
300 A
0B
MSD
200 / 250 / 257 A
400 A
0C
FDD
3 / 6 A
8 A
11
FDD
5 / 10 A
15 A
12
FDD
9 / 18 A
25 A
14
FDD
18 / 36 A
50 A
16
FDD
28 / 56 A
80 A
17
FDD
56 / 112 A
160 A
19
FDD
70 / 140 A
200 A
1A
FDD
140 / 210 A
400 A
1C
Power section
selection
