Addr. Parameter C Setting Options Default Setting Comments
2243 I Max InRr. 3I0 0.30 .. 25.00 I/InS 7.50 I/InS Maximum Current for Inr.
Rest. O/C 3I0
2311 3I0>> 1A 0.05 .. 35.00 A; ∞ 7.00 A 3I0>> Pickup
5A 0.25 .. 175.00 A; ∞ 35.00 A
2312 3I0>> 0.05 .. 35.00 I/InS; ∞ 7.00 I/InS 3I0>> Pickup
2313 T 3I0>> 0.00 .. 60.00 sec; ∞ 1.50 sec T 3I0>> Time Delay
2314 3I0> 1A 0.05 .. 35.00 A; ∞ 1.50 A 3I0> Pickup
5A 0.25 .. 175.00 A; ∞ 7.50 A
2315 3I0> 0.05 .. 35.00 I/InS; ∞ 1.50 I/InS 3I0> Pickup
2316 T 3I0> 0.00 .. 60.00 sec; ∞ 2.00 sec T 3I0> Time Delay
2321 3I0p 1A 0.05 .. 4.00 A 1.00 A 3I0p Pickup
5A 0.25 .. 20.00 A 5.00 A
2322 3I0p 0.05 .. 4.00 I/InS 1.00 I/InS 3I0p Pickup
2323 T 3I0p 0.05 .. 3.20 sec; ∞ 0.50 sec T 3I0p Time Dial
2324 D 3I0p 0.50 .. 15.00 ; ∞ 5.00 D 3I0p Time Dial
Information List
No. Information Type of
Informa-
tion
Comments
191.2404 >BLK 3I0 O/C SP >BLOCK 3I0 time overcurrent
191.2411 O/C 3I0 OFF OUT Time Overcurrent 3I0 is OFF
191.2412 O/C 3I0 BLK OUT Time Overcurrent 3I0 is BLOCKED
191.2413 O/C 3I0 ACTIVE OUT Time Overcurrent 3I0 is ACTIVE
191.2425 O/C 3I0 PU OUT Time Overcurrent 3I0 picked up
191.2491 O/C 3I0 Not av. OUT O/C 3I0: Not available for this object
191.2501 >BLK 3I0O/C Inr SP >BLOCK time overcurrent 3I0 InRush
191.2502 >BLOCK 3I0>> SP >BLOCK 3I0>> time overcurrent
191.2503 >BLOCK 3I0> SP >BLOCK 3I0> time overcurrent
191.2504 >BLOCK 3I0p SP >BLOCK 3I0p time overcurrent
191.2514 3I0>> BLOCKED OUT 3I0>> BLOCKED
191.2515 3I0> BLOCKED OUT 3I0> BLOCKED
191.2516 3I0p BLOCKED OUT 3I0p BLOCKED
191.2521 3I0>> picked up OUT 3I0>> picked up
191.2522 3I0> picked up OUT 3I0> picked up
191.2523 3I0p picked up OUT 3I0p picked up
191.2524 3I0> InRush PU OUT 3I0> InRush picked up
191.2525 3I0p InRush PU OUT 3I0p InRush picked up
191.2529 3I0 InRush PU OUT 3I0 InRush picked up
191.2541 3I0>> Time Out OUT 3I0>> Time Out
191.2542 3I0> Time Out OUT 3I0> Time Out
191.2543 3I0p TimeOut OUT 3I0p Time Out
191.2551 3I0>> TRIP OUT 3I0>> TRIP
191.2552 3I0> TRIP OUT 3I0> TRIP
191.2553 3I0p TRIP OUT 3I0p TRIP
2.4.3.3
Functions
2.4 Time Overcurrent Protection for Phase and Residual Currents
160 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
