Default Settings LEDs
Table E-1 7UT612
LEDs Allocated Function Function No. Description
LED1 Relay TRIP 511 Relay GENERAL TRIP command
LED2 Relay PICKUP 501 Relay PICKUP
LED3 >Buchh. Trip 392 >Tripp. stage from Buchholz protection
LED4 no default setting - -
LED5 no default setting - -
LED6 Error Sum Alarm 140 Error with a summary alarm
Alarm Sum Event 160 Alarm Summary Event
LED7 FaultConfig/Set 311 Fault in configuration / setting
Table E-2 7UT613/63x
LEDs Allocated Function Function No. Description
LED1 Relay TRIP 511 Relay GENERAL TRIP command
LED2 Relay PICKUP 501 Relay PICKUP
LED3 >Buchh. Trip 392 >Tripp. stage from Buchholz protection
LED4 no default setting - -
LED5 no default setting - -
LED6 no default setting - -
LED7 no default setting - -
LED8 no default setting - -
LED9 no default setting - -
LED10 no default setting - -
LED11 no default setting - -
LED12 no default setting - -
LED13 Error Sum Alarm 140 Error with a summary alarm
Alarm Sum Event 160 Alarm Summary Event
LED14 FaultConfig/Set 311 Fault in configuration / setting
E.1
Default Settings and Protocol-dependent Functions
E.1 Default Settings LEDs
530 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
