Information List
Indications for IEC 60 870-5-103 are always reported ON / OFF if they are subject to general interrogation for
IEC 60 870-5-103. If not, they are reported only as ON.
New user-defined indications or such newly allocated to IEC 60 870-5-103 are set to ON / OFF and subjected
to general interrogation if the information type is not a spontaneous event (“.._Ev”“). Further information on
indications can be found in detail in the SIPROTEC 4 System Description, Order No. E50417-H1176-C151.
In columns “Event Log”, “Trip Log” and “Ground Fault Log” the following applies:
UPPER CASE NOTATION “ON/OFF”: definitely set, not allocatable
lower case notation “on/off”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
In the column “Marked in Oscill. Record” the following applies:
UPPER CASE NOTATION “M”: definitely set, not allocatable
lower case notation “m”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
- Reset LED (Reset LED) Device IntS
P
O
N
* * LED BO 17
6
19 1 No
- Test mode (Test mode) Device IntS
P
O
N
OF
F
* * LED BO 17
6
21 1 Yes
- Stop data transmission
(DataStop)
Device IntS
P
O
N
OF
F
* * LED BO 17
6
20 1 Yes
- Unlock data transmission
via BI (UnlockDT)
Device IntS
P
* * * LED BO
- >Back Light on (>Light
on)
Device SP O
N
OF
F
* * LED BI BO
- Clock Synchronization
(SynchClock)
Device IntS
P_E
v
* * * LED BO
- Hardware Test Mode
(HWTestMod)
Device IntS
P
O
N
OF
F
* * LED BO
F.3
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7UT6x, Manual 587
C53000-G1176-C230-5, Edition 09.2016
To Next Page
