Page #532 background imageLoading...
Page #532 background image
Default Settings Binary Outputs
Table E-4 Output relay default settings for all devices and ordering variants
Binary Output Allocated Function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
BO2 Relay PICKUP 501 Relay PICKUP
BO3 >Buchh. Trip 392 >Tripp. stage from Buchholz protection
BO4 Error Sum Alarm 140 Error with a summary alarm
Alarm Sum Event 160 Alarm Summary Event
E.3
Default Settings and Protocol-dependent Functions
E.3 Default Settings Binary Outputs
532 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
