Addr. Parameter C Setting Options Default Setting Comments
4034 FACTOR K 1.0 .. 100.0 sec; ∞ 18.7 sec Negativ Sequence Factor K
4035 T COOL DOWN 0 .. 50000 sec 1650 sec Time for Cooling Down
Information List
No. Information Type of
Informa-
tion
Comments
5143 >BLOCK I2 SP >BLOCK I2 (Unbalance Load)
5146 >RM th.rep. I2 SP >Reset memory for thermal replica I2
5151 I2 OFF OUT I2 switched OFF
5152 I2 BLOCKED OUT I2 is BLOCKED
5153 I2 ACTIVE OUT I2 is ACTIVE
5157 I2 th. Warn OUT Unbalanced load: Thermal warning stage
5158 RM th.rep. I2 OUT Reset memory of thermal replica I2
5159 I2>> picked up OUT I2>> picked up
5160 I2>> TRIP OUT Unbalanced load: TRIP of current stage
5161 I2 Θ TRIP OUT Unbalanced load: TRIP of thermal stage
5165 I2> picked up OUT I2> picked up
5166 I2p picked up OUT I2p picked up
5167 I2th Pick-up OUT Unbalanced load: Pick-up I2 thermal
5168 I2 Adap.fact. OUT I2 err.: adverse Adaption factor CT
5170 I2 TRIP OUT I2 TRIP
5172 I2 Not avail. OUT I2 err.: Not available for this object
5178 I2> TRIP OUT I2> TRIP
5179 I2p TRIP OUT I2p TRIP
2.8.4
Functions
2.8 Unbalanced Load Protection
SIPROTEC 4, 7UT6x, Manual 199
C53000-G1176-C230-5, Edition 09.2016
