1. Circuit breaker failure protection 70xx 047.xxxx(.01)
2. Circuit breaker failure protection 71xx 206.xxxx(.01)
Settings
Addr. Parameter Setting Options Default Setting Comments
7001 BREAKER FAILURE OFF
ON
Block relay
OFF Breaker Failure Protection
7011 START WITH REL. 0 .. 8 0 Start with Relay (intern)
7012 START WITH REL. 0 .. 24 0 Start with Relay (intern)
7015 T1 0.00 .. 60.00 sec; ∞ 0.15 sec T1, Delay of 1st stage (local trip)
7016 T2 0.00 .. 60.00 sec; ∞ 0.30 sec T2, Delay of 2nd stage (busbar
trip)
Information List
No. Information Type of
Informa-
tion
Comments
047.2404 >BLOCK BkrFail SP >BLOCK Breaker failure
047.2411 BkrFail OFF OUT Breaker failure is switched OFF
047.2412 BkrFail BLOCK OUT Breaker failure is BLOCKED
047.2413 BkrFail ACTIVE OUT Breaker failure is ACTIVE
047.2491 BkrFail Not av. OUT Breaker failure Not avail. for this obj.
047.2651 >BrkFail extSRC SP >Breaker failure initiated externally
047.2652 BkrFail int PU OUT Breaker failure (internal) PICKUP
047.2653 BkrFail ext PU OUT Breaker failure (external) PICKUP
047.2654 BF T1-TRIP(loc) OUT BF TRIP T1 (local trip)
047.2655 BF T2-TRIP(bus) OUT BF TRIP T2 (busbar trip)
2.17.3
2.17.4
Functions
2.17 Circuit Breaker Failure Protection
250 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
