Functional Scope
Addr. Information Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Grp Chge OPTION Grp Chge OPTION
105 PROT. OBJECT 3 phase transf.
1 phase transf.
Autotransf.
Autotr. node
Generator/Motor
3ph Busbar
1ph Busbar
PROT. OBJECT PROT. OBJECT
112 DIFF. PROT. Disabled
Enabled
DIFF. PROT. DIFF. PROT.
113 REF PROT. Disabled
Enabled
REF PROT. REF PROT.
114 REF PROT. 2 Disabled
Enabled
REF PROT. 2 REF PROT. 2
117 COLDLOAD PICKUP Disabled
Enabled
COLDLOAD PICKUP COLDLOAD PICKUP
120 DMT/IDMT Phase Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT Phase DMT/IDMT Phase
130 DMT/IDMT Phase2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT Phase2 DMT/IDMT Phase2
132 DMT/IDMT Phase3 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT Phase3 DMT/IDMT Phase3
122 DMT/IDMT 3I0 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT 3I0 DMT/IDMT 3I0
F.1
Functions, Settings, Information
F.1 Functional Scope
540 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
