Addr. Information Setting Options Default Setting Comments
134 DMT/IDMT 3I0 2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT 3I0 2 DMT/IDMT 3I0 2
136 DMT/IDMT 3I0 3 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT 3I0 3 DMT/IDMT 3I0 3
124 DMT/IDMT Earth Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT Earth DMT/IDMT Earth
138 DMT/IDMT Earth2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
DMT/IDMT Earth2 DMT/IDMT Earth2
127 DMT 1PHASE Disabled
Enabled
DMT 1PHASE DMT 1PHASE
140 UNBALANCE LOAD Disabled
Definite Time
TOC IEC
TOC ANSI
DT/thermal
UNBALANCE LOAD UNBALANCE LOAD
142 THERM. OVERLOAD Disabled
th rep w.o. sen
th repl w. sens
IEC354
THERM. OVERLOAD THERM. OVERLOAD
144 THERM.OVERLOAD2 Disabled
th rep w.o. sen
th repl w. sens
IEC354
THERM.OVERLOAD2 THERM.OVERLOAD2
143 OVEREXC. PROT. Disabled
Enabled
OVEREXC. PROT. OVEREXC. PROT.
150 REVERSE POWER Disabled
Enabled
REVERSE POWER REVERSE POWER
151 FORWARD POWER Disabled
Enabled
FORWARD POWER FORWARD POWER
152 UNDERVOLTAGE Disabled
Enabled
UNDERVOLTAGE UNDERVOLTAGE
Functions, Settings, Information
F.1 Functional Scope
SIPROTEC 4, 7UT6x, Manual 541
C53000-G1176-C230-5, Edition 09.2016
