Remember to also allocate all binary inputs that are needed to generate a manual close pulse for the various
protection functions (FNo 30351 to 30360).
i
i
NOTE
In the following settings overview, the values are referred to the rated current of the assigned side (Ι/Ι
NS
).
Settings
The table indicates region-specific presettings. Column C (configuration) indicates the corresponding secon-
dary nominal current of the current transformer.
Addr. Parameter C Setting Options Default Setting Comments
1107 P,Q sign not reversed
reversed
not reversed sign of P,Q
1111 PoleOpenCurr.S1 0.04 .. 1.00 I/InS 0.10 I/InS Pole Open Current
Threshold Side 1
1112 PoleOpenCurr.S2 0.04 .. 1.00 I/InS 0.10 I/InS Pole Open Current
Threshold Side 2
1113 PoleOpenCurr.S3 0.04 .. 1.00 I/InS 0.16 I/InS Pole Open Current
Threshold Side 3
1114 PoleOpenCurr.S4 0.04 .. 1.00 I/InS 0.16 I/InS Pole Open Current
Threshold Side 4
1115 PoleOpenCurr.S5 0.04 .. 1.00 I/InS 0.16 I/InS Pole Open Current
Threshold Side 5
1121 PoleOpenCurr.M1 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold Meas.Loc. M1
5A 0.20 .. 5.00 A 0.20 A
1122 PoleOpenCurr.M2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold Meas.Loc. M2
5A 0.20 .. 5.00 A 0.20 A
1123 PoleOpenCurr.M3 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold Meas.Loc. M3
5A 0.20 .. 5.00 A 0.20 A
1124 PoleOpenCurr.M4 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold Meas.Loc. M4
5A 0.20 .. 5.00 A 0.20 A
1125 PoleOpenCurr.M5 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold Meas.Loc. M5
5A 0.20 .. 5.00 A 0.20 A
1131 PoleOpenCurr I1 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 1
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1132 PoleOpenCurr I2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 2
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1133 PoleOpenCurr I3 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 3
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1134 PoleOpenCurr I4 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 4
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1135 PoleOpenCurr I5 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 5
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
2.1.6.2
Functions
2.1 General
88 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
