Addr. Parameter Setting Options Default Setting Comments
5311 U> 30.0 .. 170.0 V 115.0 V U> Pickup
5312 U> 0.30 .. 1.70 U/UnS 1.15 U/UnS Pick-up voltage U>
5313 T U> 0.00 .. 60.00 sec; ∞ 3.00 sec T U> Time Delay
5314 U>> 30.0 .. 170.0 V 130.0 V U>> Pickup
5315 U>> 0.30 .. 1.70 U/UnS 1.30 U/UnS Pick-up voltage U>>
5316 T U>> 0.00 .. 60.00 sec; ∞ 0.50 sec T U>> Time Delay
5317A DOUT RATIO 0.90 .. 0.99 0.98 U>, U>> Drop Out Ratio
5318A VALUES U-ph-ph
U-ph-e
U-ph-ph Measurement Values
Information List
No. Information Type of
Informa-
tion
Comments
034.2404 >BLOCK O/V SP >BLOCK overvoltage protection
034.2411 Overvolt. OFF OUT Overvoltage protection is switched OFF
034.2412 Overvolt. BLK OUT Overvoltage protection is BLOCKED
034.2413 Overvolt. ACT OUT Overvoltage protection is ACTIVE
034.2491 U> err. Obj. OUT Overvoltage: Not avail. for this obj.
034.2492 U> err. VT OUT Overvoltage: error VT assignment
034.2502 >BLOCK U>> SP >BLOCK overvoltage protection U>>
034.2503 >BLOCK U> SP >BLOCK overvoltage protection U>
034.2521 U>> picked up OUT Overvoltage U>> picked up
034.2522 U> picked up OUT Overvoltage U> picked up
034.2551 U>> TRIP OUT Overvoltage U>> TRIP
034.2552 U> TRIP OUT Overvoltage U> TRIP
2.15.4
Functions
2.15 Overvoltage Protection
238 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
