Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
The table indicates region-specific presettings. Column C (configuration) indicates the corresponding secon-
dary nominal current of the current transformer.
Addr. Parameter C Setting Options Default Setting Comments
0 FLEXIBLE FUNC. OFF
ON
Alarm Only
Block relay
OFF Flexible Function
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 1
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 2
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 3
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 4
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 5
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I1
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I2
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I3
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I4
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I5
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I6
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I7
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I8
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I9
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
2.22.7.3
Functions
2.22 Auxiliary Functions
294 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
