Addr. Parameter C Setting Options Default Setting Comments
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I10
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I11
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I12
5A 0.25 .. 175.00 A 10.00 A
0.1A 0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold IX1
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold IX2
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold IX3
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold IX4
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. 0.001 .. 1.500 A 0.100 A Pick-up threshold IX3 sens.
0 Pick-up thresh. 0.001 .. 1.500 A 0.100 A Pick-up threshold IX4 sens.
0 Pick-up thresh. 0.05 .. 35.00 I/InS 2.00 I/InS Pick-up threshold I-side
0 P.U. THRESHOLD 1.0 .. 170.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD 1.0 .. 170.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD 40.00 .. 66.00 Hz 51.00 Hz Pickup Threshold
0 P.U. THRESHOLD 10.00 .. 22.00 Hz 18.00 Hz Pickup Threshold
0 P.U. THRESHOLD 1A 1.7 .. 3000.0 W 200.0 W Pickup Threshold
5A 8.5 .. 15000.0 W 1000.0 W
0 Pick-up thresh. 0.01 .. 17.00 P/SnS 1.10 P/SnS Pick-up threshold P-side
0 Pick-up thresh. 1A 1.7 .. 3000.0 VAR 200.0 VAR Pick-up threshold Q meas.
location
5A 8.5 .. 15000.0 VAR 1000.0 VAR
0 Pick-up thresh. 0.01 .. 17.00 Q/SnS 1.10 Q/SnS Pick-up threshold Q-side
0 P.U. THRESHOLD -0.99 .. 0.99 0.50 Pickup Threshold
0 T TRIP DELAY 0.00 .. 3600.00 sec 1.00 sec Trip Time Delay
0A T PICKUP DELAY 0.00 .. 60.00 sec 0.00 sec Pickup Time Delay
0A T DROPOUT DELAY 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLOCKED BY FFM YES
NO
YES Block in case of Meas.-
Voltage Loss
0A Blk I brkn cond YES
NO
YES Block for broken conductor
in CT path
0A DROPOUT RATIO 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO 1.01 .. 3.00 1.05 Dropout Ratio
Functions
2.22 Auxiliary Functions
SIPROTEC 4, 7UT6x, Manual 295
C53000-G1176-C230-5, Edition 09.2016
