Addr. Parameter C Setting Options Default Setting Comments
1136 PoleOpenCurr I6 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 6
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1137 PoleOpenCurr I7 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 7
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1138 PoleOpenCurr I8 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 8
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1139 PoleOpenCurr I9 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 9
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1140 PoleOpenCurrI10 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 10
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1141 PoleOpenCurrI11 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 11
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1142 PoleOpenCurrI12 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold End 12
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1151 PoleOpenCurrIX1 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT1
5A 0.20 .. 5.00 A 0.20 A
1152 PoleOpenCurrIX2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT2
5A 0.20 .. 5.00 A 0.20 A
1153 PoleOpenCurrIX3 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT3
5A 0.20 .. 5.00 A 0.20 A
1154 PoleOpenCurrIX4 1A 0.04 .. 1.00 A 0.04 A Pole Open Current
Threshold AuxiliaryCT4
5A 0.20 .. 5.00 A 0.20 A
Information List
No.
Information Type of
Informa-
tion
Comments
- >QuitG-TRP IntSP >Quitt Lock Out: General Trip
- G-TRP Quit IntSP Lock Out: General TRIP
126 ProtON/OFF IntSP Protection ON/OFF (via system port)
236.2127 BLK. Flex.Fct. IntSP BLOCK Flexible Function
301 Pow.Sys.Flt. OUT Power System fault
302 Fault Event OUT Fault Event
311 FaultConfig/Set OUT Fault in configuration / setting
312 GenErrGroupConn OUT Gen.err.: Inconsistency group/connection
313 GenErrEarthCT OUT Gen.err.: Sev. earth-CTs with equal typ
314 GenErrSidesMeas OUT Gen.err.: Number of sides / measurements
501 Relay PICKUP OUT Relay PICKUP
511 Relay TRIP OUT Relay GENERAL TRIP command
545 PU Time VI Time from Pickup to drop out
2.1.6.3
Functions
2.1 General
SIPROTEC 4, 7UT6x, Manual 89
C53000-G1176-C230-5, Edition 09.2016
