No. Information Type of
Informa-
tion
Comments
546 TRIP Time VI Time from Pickup to TRIP
576 IL1S1: VI Primary fault current IL1 side1
577 IL2S1: VI Primary fault current IL2 side1
578 IL3S1: VI Primary fault current IL3 side1
579 IL1S2: VI Primary fault current IL1 side2
580 IL2S2: VI Primary fault current IL2 side2
581 IL3S2: VI Primary fault current IL3 side2
582 I1: VI Primary fault current I1
583 I2: VI Primary fault current I2
584 I3: VI Primary fault current I3
585 I4: VI Primary fault current I4
586 I5: VI Primary fault current I5
587 I6: VI Primary fault current I6
588 I7: VI Primary fault current I7
30060 Gen CT-M1: VI General: Adaption factor CT M1
30061 Gen CT-M2: VI General: Adaption factor CT M2
30062 Gen CT-M3: VI General: Adaption factor CT M3
30063 Gen CT-M4: VI General: Adaption factor CT M4
30064 Gen CT-M5: VI General: Adaption factor CT M5
30065 Gen VT-U1: VI General: Adaption factor VT UL123
30067 par too low: VI parameter too low:
30068 par too high: VI parameter too high:
30069 settingFault: VI setting fault:
30070 Man.Clos.Det.M1 OUT Manual close signal meas.loc. 1 detected
30071 Man.Clos.Det.M2 OUT Manual close signal meas.loc. 2 detected
30072 Man.Clos.Det.M3 OUT Manual close signal meas.loc. 3 detected
30073 Man.Clos.Det.M4 OUT Manual close signal meas.loc. 4 detected
30074 Man.Clos.Det.M5 OUT Manual close signal meas.loc. 5 detected
30075 Man.Clos.Det.S1 OUT Manual close signal side 1 is detected
30076 Man.Clos.Det.S2 OUT Manual close signal side 2 is detected
30077 Man.Clos.Det.S3 OUT Manual close signal side 3 is detected
30078 Man.Clos.Det.S4 OUT Manual close signal side 4 is detected
30079 Man.Clos.Det.S5 OUT Manual close signal side 5 is detected
30251 IL1M1: VI Primary fault current IL1 meas. loc. 1
30252 IL2M1: VI Primary fault current IL2 meas. loc. 1
30253 IL3M1: VI Primary fault current IL3 meas. loc. 1
30254 IL1M2: VI Primary fault current IL1 meas. loc. 2
30255 IL2M2: VI Primary fault current IL2 meas. loc. 2
30256 IL3M2: VI Primary fault current IL3 meas. loc. 2
30257 IL1M3: VI Primary fault current IL1 meas. loc. 3
30258 IL2M3: VI Primary fault current IL2 meas. loc. 3
30259 IL3M3: VI Primary fault current IL3 meas. loc. 3
30260 IL1M4: VI Primary fault current IL1 meas. loc. 4
30261 IL2M4: VI Primary fault current IL2 meas. loc. 4
30262 IL3M4: VI Primary fault current IL3 meas. loc. 4
Functions
2.1 General
90 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
