Siemens SIPROTEC 4 7UT6 Series User Manual

No. Information Type of
Informa-
tion
Comments
30263 IL1M5: VI Primary fault current IL1 meas. loc. 5
30264 IL2M5: VI Primary fault current IL2 meas. loc. 5
30265 IL3M5: VI Primary fault current IL3 meas. loc. 5
30266 IL1S3: VI Primary fault current IL1 side3
30267 IL2S3: VI Primary fault current IL2 side3
30268 IL3S3: VI Primary fault current IL3 side3
30269 IL1S4: VI Primary fault current IL1 side4
30270 IL2S4: VI Primary fault current IL2 side4
30271 IL3S4: VI Primary fault current IL3 side4
30272 IL1S5: VI Primary fault current IL1 side5
30273 IL2S5: VI Primary fault current IL2 side5
30274 IL3S5: VI Primary fault current IL3 side5
30275 I8: VI Primary fault current I8
30276 I9: VI Primary fault current I9
30277 I10: VI Primary fault current I10
30278 I11: VI Primary fault current I11
30279 I12: VI Primary fault current I12
30351 >ManualClose M1 SP >Manual close signal measurement loc. 1
30352 >ManualClose M2 SP >Manual close signal measurement loc. 2
30353 >ManualClose M3 SP >Manual close signal measurement loc. 3
30354 >ManualClose M4 SP >Manual close signal measurement loc. 4
30355 >ManualClose M5 SP >Manual close signal measurement loc. 5
30356 >ManualClose S1 SP >Manual close signal side 1
30357 >ManualClose S2 SP >Manual close signal side 2
30358 >ManualClose S3 SP >Manual close signal side 3
30359 >ManualClose S4 SP >Manual close signal side 4
30360 >ManualClose S5 SP >Manual close signal side 5
Functions
2.1 General
SIPROTEC 4, 7UT6x, Manual 91
C53000-G1176-C230-5, Edition 09.2016
