Measured Values
No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Control DIGSI (CntrlDIGSI) Cntrl Authority - - - - - CD DD
- Operating hours greater than
(OpHour>)
SetPoint(Stat) - - - - - CD DD
044.26
11
Temperat. rise for warning and
trip (Θ/Θtrip =)
Meas. Thermal - - - - - CFC CD DD
044.26
12
Temperature rise for phase L1 (Θ/
ΘtripL1=)
Meas. Thermal - - - - - CFC CD DD
044.26
13
Temperature rise for phase L2 (Θ/
ΘtripL2=)
Meas. Thermal - - - - - CFC CD DD
044.26
14
Temperature rise for phase L3 (Θ/
ΘtripL3=)
Meas. Thermal - - - - - CFC CD DD
044.26
15
Hot spot temperature of leg L1 (Θ
leg L1=)
Meas. Thermal - - - - - CFC CD DD
044.26
16
Hot spot temperature of leg L2 (Θ
leg L2=)
Meas. Thermal - - - - - CFC CD DD
044.26
17
Hot spot temperature of leg L3 (Θ
leg L3=)
Meas. Thermal - - - - - CFC CD DD
044.26
18
Hot spot temperature of leg L12
(Θ leg L12=)
Meas. Thermal - - - - - CFC CD DD
044.26
19
Hot spot temperature of leg L23
(Θ leg L23=)
Meas. Thermal - - - - - CFC CD DD
044.26
20
Hot spot temperature of leg L31
(Θ leg L31=)
Meas. Thermal - - - - - CFC CD DD
044.26
21
Aging Rate (Ag.Rate=) Meas. Thermal - - - - - CFC CD DD
044.26
22
Load Reserve to warning level
(ResWARN=)
Meas. Thermal - - - - - CFC CD DD
044.26
23
Load Reserve to alarm level (ResA-
LARM=)
Meas. Thermal - - - - - CFC CD DD
199.26
40
Idiff REF (I/Inominal object [%])
(IdiffREF=)
Meas. Dif/Rest. - - - - - CFC CD DD
199.26
41
Irest REF (I/Inominal object [%])
(IrestREF=)
Meas. Dif/Rest. - - - - - CFC CD DD
204.26
11
O/L2 Temperat. rise for warning
and trip (2Θ/Θtrip =)
Meas. Thermal - - - - - CFC CD DD
204.26
12
Th. O/L 2 Temperature rise for
phase L1 (2Θ/ΘtrpL1=)
Meas. Thermal - - - - - CFC CD DD
204.26
13
Th. O/L 2 Temperature rise for
phase L2 (2Θ/ΘtrpL2=)
Meas. Thermal - - - - - CFC CD DD
204.26
14
Th. O/L 2 Temperature rise for
phase L3 (2Θ/ΘtrpL3=)
Meas. Thermal - - - - - CFC CD DD
F.5
Functions, Settings, Information
F.5 Measured Values
656 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
