At address 7612 DMD Sync.Time it can be determined whether the point in time for averaging selected
under address 7611 is to commence on the hour (On The Hour) or is to be synchronised with another point
in time (15 After Hour, 30 After Hour or 45 After Hour).
If the settings for averaging are changed, then the measured values stored in the buffer are deleted, and new
results for the average calculation are only available after the set time period has passed.
Settings
Addr. Parameter Setting Options Default Setting Comments
7611 DMD Interval 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
7612 DMD Sync.Time On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
Min/Max Measurement Setup
Setting Notes
Resetting of the minimum and maximum values can also be done cyclically, commencing with the preselected
starting time. To select this feature, address 7621 MinMax cycRESET should be set to YES. The point in time
when reset is to take place (the minute of the day in which reset will take place) is set at address 7622 MiMa
RESET TIME. The reset cycle in days is entered at address 7623 MiMa RESETCYCLE, and the beginning date
of the cyclical process, from the time of the setting procedure (in days), is entered at address 7624
MinMaxRES.START.
Settings
Addr.
Parameter Setting Options Default Setting Comments
7621 MinMax cycRESET NO
YES
YES Automatic Cyclic Reset Function
7622 MiMa RESET TIME 0 .. 1439 min 0 min MinMax Reset Timer
7623 MiMa RESETCYCLE 1 .. 365 Days 7 Days MinMax Reset Cycle Period
7624 MinMaxRES.START 1 .. 365 Days 1 Days MinMax Start Reset Cycle in
Information List
No.
Information Type of
Informa-
tion
Comments
- ResMinMax IntSP_Ev Reset Minimum and Maximum counter
11001 >Reset MinMax SP >Reset MinMaxValues
2.23.1.2
2.23.2
2.23.2.1
2.23.2.2
2.23.2.3
Functions
2.23 Average Values, Minimum and Maximum Values
302 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
