Siemens SIPROTEC 4 7UT6 Series - Information List

Information List
No. Information Type of
Informa-
tion
Comments
024.2404 >BLK Earth O/C SP >BLOCK Earth time overcurrent
024.2411 O/C Earth OFF OUT Time Overcurrent Earth is OFF
024.2412 O/C Earth BLK OUT Time Overcurrent Earth is BLOCKED
024.2413 O/C Earth ACT OUT Time Overcurrent Earth is ACTIVE
024.2425 O/C Earth PU OUT Time Overcurrent Earth picked up
024.2492 O/C Earth ErrCT OUT O/C Earth err.: No auxiliary CT assigned
024.2501 >BLK E O/C Inr SP >BLOCK time overcurrent Earth InRush
024.2502 >BLOCK IE>> SP >BLOCK IE>>
024.2503 >BLOCK IE> SP >BLOCK IE>
024.2504 >BLOCK IEp SP >BLOCK IEp
024.2514 IE>> BLOCKED OUT IE>> BLOCKED
024.2515 IE> BLOCKED OUT IE> BLOCKED
024.2516 IEp BLOCKED OUT IEp BLOCKED
024.2521 IE>> picked up OUT IE>> picked up
024.2522 IE> picked up OUT IE> picked up
024.2523 IEp picked up OUT IEp picked up
024.2524 IE> InRush PU OUT IE> InRush picked up
024.2525 IEp InRush PU OUT IEp InRush picked up
024.2529 Earth InRush PU OUT Earth InRush picked up
024.2541 IE>> Time Out OUT IE>> Time Out
024.2542 IE> Time Out OUT IE> Time Out
024.2543 IEp TimeOut OUT IEp Time Out
024.2551 IE>> TRIP OUT IE>> TRIP
024.2552 IE> TRIP OUT IE> TRIP
024.2553 IEp TRIP OUT IEp TRIP
2.5.9
Functions
2.5 Time Overcurrent Protection for Earth Current
SIPROTEC 4, 7UT6x, Manual 171
C53000-G1176-C230-5, Edition 09.2016
