Addr. Parameter C Setting Options Default Setting Comments
2408A IE MAN. CLOSE IE>> instant.
IE> instant.
IEp instant.
Inactive
IE>> instant. O/C IE Manual Close Mode
2411 IE>> 1A 0.05 .. 35.00 A; ∞ 1.00 A IE>> Pickup
5A 0.25 .. 175.00 A; ∞ 5.00 A
2412 T IE>> 0.00 .. 60.00 sec; ∞ 1.50 sec T IE>> Time Delay
2413 IE> 1A 0.05 .. 35.00 A; ∞ 0.40 A IE> Pickup
5A 0.25 .. 175.00 A; ∞ 2.00 A
2414 T IE> 0.00 .. 60.00 sec; ∞ 2.00 sec T IE> Time Delay
2421 IEp 1A 0.05 .. 4.00 A 0.40 A IEp Pickup
5A 0.25 .. 20.00 A 2.00 A
2422 T IEp 0.05 .. 3.20 sec; ∞ 0.50 sec T IEp Time Dial
2423 D IEp 0.50 .. 15.00 ; ∞ 5.00 D IEp Time Dial
2424 TOC DROP-OUT Instantaneous
Disk Emulation
Disk Emulation TOC Drop-out Character-
istic
2425 IEC CURVE Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
2426 ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
2431 I/IEp PU T/TEp 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
Pickup Curve IE/IEp - TIE/
TIEp
2432 MofPU Res T/TEp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> TI/
TIEp
2441 2.HARM. Earth 10 .. 45 % 15 % 2nd harmonic O/C E in % of
fundamental
2442 I Max InRr. E 1A 0.30 .. 25.00 A 7.50 A Maximum Current for Inr.
Rest. O/C Earth
5A 1.50 .. 125.00 A 37.50 A
2511 IE>> 1A 0.05 .. 35.00 A; ∞ 7.00 A IE>> Pickup
5A 0.25 .. 175.00 A; ∞ 35.00 A
2512 T IE>> 0.00 .. 60.00 sec; ∞ 1.50 sec T IE>> Time Delay
2513 IE> 1A 0.05 .. 35.00 A; ∞ 1.50 A IE> Pickup
5A 0.25 .. 175.00 A; ∞ 7.50 A
2514 T IE> 0.00 .. 60.00 sec; ∞ 2.00 sec T IE> Time Delay
2521 IEp 1A 0.05 .. 4.00 A 1.00 A IEp Pickup
5A 0.25 .. 20.00 A 5.00 A
2522 T IEp 0.05 .. 3.20 sec; ∞ 0.50 sec T IEp Time Dial
2523 D IEp 0.50 .. 15.00 ; ∞ 5.00 D IEp Time Dial
Functions
2.5 Time Overcurrent Protection for Earth Current
170 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
