Addr. Parameter C Setting Options Default Setting Comments
8105 PHASE ROTAT. I ON
OFF
OFF Current Phase Rotation
Supervision
8106 PHASE ROTAT. U ON
OFF
OFF Voltage Phase Rotation
Supervision
8111 BAL. I LIMIT M1 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 1
5A 0.50 .. 5.00 A 2.50 A
8112 BAL. FACT. I M1 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.1
8113A T Sym. I th. M1 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8121 BAL. I LIMIT M2 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 2
5A 0.50 .. 5.00 A 2.50 A
8122 BAL. FACT. I M2 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.2
8123A T Sym. I th. M2 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8131 BAL. I LIMIT M3 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 3
5A 0.50 .. 5.00 A 2.50 A
8132 BAL. FACT. I M3 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.3
8133A T Sym. I th. M3 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8141 BAL. I LIMIT M4 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 4
5A 0.50 .. 5.00 A 2.50 A
8142 BAL. FACT. I M4 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.4
8143A T Sym. I th. M4 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8151 BAL. I LIMIT M5 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 5
5A 0.50 .. 5.00 A 2.50 A
8152 BAL. FACT. I M5 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.5
8153A T Sym. I th. M5 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8161 BALANCE U-LIMIT 10 .. 100 V 50 V Voltage Threshold for
Balance Monitoring
8162 BAL. FACTOR U 0.58 .. 0.90 0.75 Balance Factor for Voltage
Monitor
8163A T BAL. U LIMIT 5 .. 100 sec 5 sec T Balance Factor for
Voltage Monitor
Information List
No.
Information Type of
Informa-
tion
Comments
161 Fail I Superv. OUT Failure: General Current Supervision
163 Fail I balance OUT Failure: Current Balance
164 Fail U Superv. OUT Failure: General Voltage Supervision
165 Fail Σ U Ph-E OUT Failure: Voltage Summation Phase-Earth
2.19.1.6
Functions
2.19 Monitoring Functions
258 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
