No. Information Type of
Informa-
tion
Comments
200.2451 O/C 1Ph TRIP OUT Time Overcurrent 1Phase TRIP
200.2492 O/C 1Ph Err CT OUT O/C 1Phase err.:No auxiliary CT assigned
200.2502 >BLK 1Ph. I>> SP >BLOCK Time Overcurrent 1Ph. I>>
200.2503 >BLK 1Ph. I> SP >BLOCK Time Overcurrent 1Ph. I>
200.2514 O/C 1Ph I>> BLK OUT Time Overcurrent 1Phase I>> BLOCKED
200.2515 O/C 1Ph I> BLK OUT Time Overcurrent 1Phase I> BLOCKED
200.2521 O/C 1Ph I>> PU OUT Time Overcurrent 1Phase I>> picked up
200.2522 O/C 1Ph I> PU OUT Time Overcurrent 1Phase I> picked up
200.2551 O/C1Ph I>> TRIP OUT Time Overcurrent 1Phase I>> TRIP
200.2552 O/C 1Ph I> TRIP OUT Time Overcurrent 1Phase I> TRIP
200.2561 O/C 1Ph I: VI Time Overcurrent 1Phase: I at pick up
Functions
2.7 Single-Phase Time Overcurrent Protection
