No. Information Type of
Informa-
tion
Comments
- Error FMS2 OUT Error FMS FO 2
- Distur.CFC OUT Disturbance CFC
68 Clock SyncError OUT Clock Synchronization Error
110 Event Lost OUT_Ev Event lost
113 Flag Lost OUT Flag Lost
140 Error Sum Alarm OUT Error with a summary alarm
160 Alarm Sum Event OUT Alarm Summary Event
169 VT FuseFail>10s OUT VT Fuse Failure (alarm >10s)
170 VT FuseFail OUT VT Fuse Failure (alarm instantaneous)
177 Fail Battery OUT Failure: Battery empty
181 Error MeasurSys OUT Error: Measurement system
183 Error Board 1 OUT Error Board 1
184 Error Board 2 OUT Error Board 2
185 Error Board 3 OUT Error Board 3
186 Error Board 4 OUT Error Board 4
187 Error Board 5 OUT Error Board 5
188 Error Board 6 OUT Error Board 6
189 Error Board 7 OUT Error Board 7
190 Error Board 0 OUT Error Board 0
191 Error Offset OUT Error: Offset
192 Error1A/5Awrong OUT Error:1A/5Ajumper different from setting
193 Alarm adjustm. OUT Alarm: Analog input adjustment invalid
196 Fuse Fail M.OFF OUT Fuse Fail Monitor is switched OFF
198 Err. Module B OUT Error: Communication Module B
199 Err. Module C OUT Error: Communication Module C
200 Err. Module D OUT Error: Communication Module D
251 Broken wire OUT Broken wire detected
264 Fail: RTD-Box 1 OUT Failure: RTD-Box 1
267 Fail: RTD-Box 2 OUT Failure: RTD-Box 2
361 >FAIL:Feeder VT SP >Failure: Feeder VT (MCB tripped)
5010 >FFM BLOCK SP >BLOCK fuse failure monitor
30054 Broken wire OFF OUT Broken wire is switched OFF
30097 Err. IN CT M1 OUT Err: inconsist. jumper/setting CT M1
30098 Err. IN CT M2 OUT Err: inconsist. jumper/setting CT M2
30099 Err. IN CT M3 OUT Err: inconsist. jumper/setting CT M3
30100 Err. IN CT M4 OUT Err: inconsist. jumper/setting CT M4
30101 Err. IN CT M5 OUT Err: inconsist. jumper/setting CT M5
30102 Err.IN CT1..3 OUT Err: inconsist. jumper/setting CT I1..3
30103 Err.IN CT4..6 OUT Err: inconsist. jumper/setting CT I4..6
30104 Err.IN CT7..9 OUT Err: inconsist. jumper/setting CT I7..9
30105 Err.IN CT10..12 OUT Err:inconsist. jumper/setting CT I10..12
30106 Err. IN CT IX1 OUT Err: inconsist. jumper/setting CT IX1
30107 Err. IN CT IX2 OUT Err: inconsist. jumper/setting CT IX2
30108 Err. IN CT IX3 OUT Err: inconsist. jumper/setting CT IX3
30109 Err. IN CT IX4 OUT Err: inconsist. jumper/setting CT IX4
Functions
2.19 Monitoring Functions
SIPROTEC 4, 7UT6x, Manual 267
C53000-G1176-C230-5, Edition 09.2016
