Application Jumpers
3-phase 1-phase individual common
Ι
L1M2
Ι4
X65
X81
Ι
L2M2
Ι5
X66
Ι
L3M2
Ι6
X67
Ι
Z1
(Ι
L1M5
)
1
)
— X64 X83
Ι
Z3
(Ι
L2M5
)
1
)
— X68
X84/X85/X86
Ι
Z3
(sensitive)
— —
1)
IN-01 in 7UT635 applicable for measuring location M5
Input/Output Board C-I/O-9 (only 7UT635)
7UT635 contains a second board C-I/O-9. Mounting location: Slot 19 right side
[ein-ausgabebgr-c-io-9-040403-st, 1, en_GB]
Figure 3-13
Input/output boards with representation of the jumpers required for checking the settings
Mounting and Commissioning
3.1 Mounting and Connections
334 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
