Test voltage (reg. socket) 500 V; 50 Hz
Transmission speed 100 MBit/s
Bridgeable distance 65.62 feet (20 m)
Ethernet optical (EN100) for DIGSI, IEC61850
Connection for Flush-mounted case rear panel, slot position “B”, duplex LC, 100BaseT acc. to IEEE802.3
Connection for Surface-mounted
case
not available
Transmission Speed 100 MBit/s
Optical wavelength 1300 nm
bridgeable distance max. 0.93 miles (1.5 km)
1)
limited selection of baud rates for 7UT612
Additional Interface
Connection isolated interface for data transfer with an RTD-box
Transmission Speed
min. 4,800 Baud; max. 115,200 Baud; Factory setting 38,400 Baud
1)
RS485
Connection for flush-mounted
casing
rear panel, mounting location “D”,
9-pole D-SUB miniature female connector
Connection for surface-mounted
casing
at the housing bottom; shielded data cable
Test Voltage 500 VAC; 50 Hz
Maximum Distance of Transmission 3,280 feet (1,000 m)
Fiber Optical Link (FO)
FO connector type ST connector
Connection for flush-mounted
casing
Rear panel, mounting location “D”
Connection for surface-mounted
casing
at the housing mounted case on the case bottom
Optical Wavelength λ = 820 nm
Laser Class 1 according to EN
60825-1/-2
using glass fiber 50/125 μm or using glass fiber 62.5/125 μm
Permissible Optical Link Signal
Attenuation
max. 8 dB, with glass fiber 62.5/125 μm
Maximum Distance of Transmission max. 0.93 miles (1.5 km)
Character Idle State Configurable: factory setting “Light off”
1)
limited selection of baud rates for 7UT612
Time Synchronization Interface
Time Synchronization
DCF 77 / IRIG B Signal
Connection for flush-mounted case Rear panel, mounting location “A”;
9-pin D-subminiature female connector
Connection for surface mounting
housing
at the double-deck terminal on the case bottom
Signal Nominal Voltages selectable 5 V, 12 V or 24 V
Test Voltage 500 V; 50 Hz
Technical Data
4.1 General
402 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
