7UT635
In surface-mounted housing, size
1
/
1
In surface-mounted housing, size
1
/
1
1)
In flush-mounted housing, size
1
/
1
22,7 kg
26,0 kg
14,5 kg
Degree of protection acc. to IEC 60529
For the device in surface-mounted housing IP 51
For the device in flush-mounted housing
Front IP 51
Back IP 50
For human safety IP 2x with closed protection cover
UL-certification conditions Type 1 for front panel mounting
Surrounding air temperatur:
tsurr: max 70
o
C, normal operation
1)
mit Transportsicherung
Technical Data
4.1 General
SIPROTEC 4, 7UT6x, Manual 407
C53000-G1176-C230-5, Edition 09.2016
