Siemens SIPROTEC 4 7UT6 Series User Manual

System Interfaces (rear side, port B) Pos. 11
Profibus FMS Slave, optical, single ring, ST connector
1)
5
Profibus FMS Slave, optical, double ring, ST connector
1)
6
For more interface options see Additional Specification L 9
1)
Not possible with surface mounting housing (position 9 = B). For the surface mounted version, please order a device
with the appropriate electrical RS485 interface and accessories as stated in A Ordering Information and Accessories
under “External Converters”
Additional Specification L for Further System Interfaces (device rear port B)
(only if Pos. 11 = 9)
Pos. 21 Pos. 22
Profibus DP Slave, RS485 0 A
Profibus DP Slave, optical, 820 nm, double ring, ST connector
1)
0 B
Modbus, RS485 0 D
Modbus, optical, 820 nm, ST connector
2)
0 E
DNP3.0, RS485 0 G
DNP3.0, optical, 820 nm, ST connector
2)
0 H
IEC 61 850, 100 Mbit Ethernet, doppelt electrical, RJ45 connector 0 R
IEC 61 850, 100 Mbit Ethernet, optical, Duplex-LC connector
2)
0 S
1)
Not possible with surface mounting housing (position 9 = B). For the surface mounted version, please order a device
with the appropriate electrical RS485 interface and accessories as stated in A Ordering Information and Accessories
under “External Converters”
2)
Cannot be delivered in connection with 9th digit = B
Function Interface (rear side, port C) Pos. 12
DIGSI/Modem/Browser, electrical RS232 1
DIGSI/Modem/Browser/RTD-box, electrical RS485 2
For further interface options see Additional Specification M 9
Additional Specification M for Further Function Interfaces
(device rear port C and D) (only if Pos. 12 = 9)
Pos. 23 Pos. 24
Port C: DIGSI/Modem/Browser, electrical RS232 1
Port C: DIGSI/Modem/Browser/RTD-box, electrical RS485 2
Port D: RTD box, optical, 820 nm, ST connector
1)
A
Port D: RTD box, elektrical RS485 F
1)
In case of a connection to a RTD box 7XV5662-xAD10, a RS485-LWL converter 7XV5650-0xA00 is required
Measurement Function Pos. 13
Basic measured values 1
Basic measured values, average values, min/max values 2
Basic measured values, average values, min/max values, transformer monitoring functions (connection to RTD
box/hot-spot, overload factor)
1)
4
1)
Only in connection with position 12 = 2 or 9 and Mxx (supplementary)
Ordering Information and Accessories
A.3 1.1.3 Differential Protection 7UT633 and 7UT635 for 3 to 5 measuring locations
478 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
