Addr. Parameter Function C Setting Options Default Setting Comments
0 Func. assigned Flx Please select
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
Please select Function is applied to
0 Func. per phase Flx Please select
UL1E..UL3E
UL1E
UL2E
UL3E
UL12..UL31
UL12
UL23
UL31
U0 (Zero seq.)
U1 (Pos. seq.)
U2 (Neg. seq.)
U4/Uen
Please select Function utilises compo-
nent(s)
0 PICKUP WITH Flx Exceeding
Dropping below
Exceeding Pickup with
0A Type of meas. Flx accurate
fast
accurate Selection of type of meas-
urement
0 FLEXIBLE FUNC. Flx OFF
ON
Alarm Only
Block relay
OFF Flexible Function
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 1
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 2
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 3
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 4
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I meas.
location 5
5A 0.25 .. 175.00 A 10.00 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I1
5A 0.25 .. 175.00 A 10.00 A
0.1
A
0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I2
5A 0.25 .. 175.00 A 10.00 A
0.1
A
0.005 .. 3.500 A 0.200 A
0 Pick-up thresh. Flx 1A 0.05 .. 35.00 A 2.00 A Pick-up threshold I3
5A 0.25 .. 175.00 A 10.00 A
0.1
A
0.005 .. 3.500 A 0.200 A
Functions, Settings, Information
F.2 Settings
544 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
