No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
033.25
51
Undervoltage U<< TRIP
(U<< TRIP)
Under-
voltage
OUT * ON * LED BO 74 40 2 Yes
033.25
52
Undervoltage U< TRIP (U<
TRIP)
Under-
voltage
OUT * ON * LED BO 74 39 2 Yes
034.24
04
>BLOCK overvoltage
protection (>BLOCK O/V)
Overvoltage SP * * * LED BI BO
034.24
11
Overvoltage protection is
switched OFF (Overvolt.
OFF)
Overvoltage OUT O
N
OF
F
* * LED BO 74 65 1 Yes
034.24
12
Overvoltage protection is
BLOCKED (Overvolt. BLK)
Overvoltage OUT O
N
OF
F
ON
OFF
* LED BO 74 66 1 Yes
034.24
13
Overvoltage protection is
ACTIVE (Overvolt. ACT)
Overvoltage OUT O
N
OF
F
ON
OFF
* LED BO 74 67 1 Yes
034.24
91
Overvoltage: Not avail.
for this obj. (U> err. Obj.)
Overvoltage OUT O
N
* * LED BO
034.24
92
Overvoltage: error VT
assignment (U> err. VT)
Overvoltage OUT O
N
* * LED BO
034.25
02
>BLOCK overvoltage
protection U>> (>BLOCK
U>>)
Overvoltage SP O
N
OF
F
ON
OFF
* LED BI BO 74 21 1 Yes
034.25
03
>BLOCK overvoltage
protection U> (>BLOCK
U>)
Overvoltage SP O
N
OF
F
ON
OFF
* LED BI BO 74 20 1 Yes
034.25
21
Overvoltage U>> picked
up (U>> picked up)
Overvoltage OUT * ON
OFF
* LED BO 74 71 2 Yes
034.25
22
Overvoltage U> picked up
(U> picked up)
Overvoltage OUT * ON
OFF
* LED BO 74 68 2 Yes
034.25
51
Overvoltage U>> TRIP
(U>> TRIP)
Overvoltage OUT * ON * LED BO 74 73 2 Yes
034.25
52
Overvoltage U> TRIP (U>
TRIP)
Overvoltage OUT * ON * LED BO 74 70 2 Yes
044.24
04
>BLOCK Thermal Over-
load Protection (>BLK
ThOverload)
Therm.
Overload
SP * * * LED BI BO 16
7
3 1 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7UT6x, Manual 595
C53000-G1176-C230-5, Edition 09.2016
