No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
30351 >Manual close signal
measurement loc. 1
(>ManualClose M1)
P.System
Data 2
SP * * * LED BI BO
30352 >Manual close signal
measurement loc. 2
(>ManualClose M2)
P.System
Data 2
SP * * * LED BI BO
30353 >Manual close signal
measurement loc. 3
(>ManualClose M3)
P.System
Data 2
SP * * * LED BI BO
30354 >Manual close signal
measurement loc. 4
(>ManualClose M4)
P.System
Data 2
SP * * * LED BI BO
30355 >Manual close signal
measurement loc. 5
(>ManualClose M5)
P.System
Data 2
SP * * * LED BI BO
30356 >Manual close signal side
1 (>ManualClose S1)
P.System
Data 2
SP * * * LED BI BO
30357 >Manual close signal side
2 (>ManualClose S2)
P.System
Data 2
SP * * * LED BI BO
30358 >Manual close signal side
3 (>ManualClose S3)
P.System
Data 2
SP * * * LED BI BO
30359 >Manual close signal side
4 (>ManualClose S4)
P.System
Data 2
SP * * * LED BI BO
30360 >Manual close signal side
5 (>ManualClose S5)
P.System
Data 2
SP * * * LED BI BO
30361 >disconnect without test:
current = 0 (>disconn.
I>=0)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
30362 >disconnect measurment
location 1 (>disconnect
M1)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
30363 >disconnect measurment
location 2 (>disconnect
M2)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
30364 >disconnect measurment
location 3 (>disconnect
M3)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7UT6x, Manual 649
C53000-G1176-C230-5, Edition 09.2016
