Siemens SIPROTEC 4 7UT6 Series User Manual

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
30376 >disconnect end 10
(>disconnect I10)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
30377 >disconnect end 11
(>disconnect I11)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
30378 >disconnect end 12
(>disconnect I12)
Discon.Mea
sLoc
SP O
N
OF
F
* * LED BI BO
30607 Accumulation of inter-
rupted curr. L1 S1
(ΣIL1S1:)
Statistics VI
30608 Accumulation of inter-
rupted curr. L2 S1
(ΣIL2S1:)
Statistics VI
30609 Accumulation of inter-
rupted curr. L3 S1
(ΣIL3S1:)
Statistics VI
30610 Accumulation of inter-
rupted curr. L1 S2
(ΣIL1S2:)
Statistics VI
30611 Accumulation of inter-
rupted curr. L2 S2
(ΣIL2S2:)
Statistics VI
30612 Accumulation of inter-
rupted curr. L3 S2
(ΣIL3S2:)
Statistics VI
30620 Accumulation of inter-
rupted curr. I1 (ΣI1:)
Statistics VI
30621 Accumulation of inter-
rupted curr. I2 (ΣI2:)
Statistics VI
30622 Accumulation of inter-
rupted curr. I3 (ΣI3:)
Statistics VI
30623 Accumulation of inter-
rupted curr. I4 (ΣI4:)
Statistics VI
30624 Accumulation of inter-
rupted curr. I5 (ΣI5:)
Statistics VI
30625 Accumulation of inter-
rupted curr. I6 (ΣI6:)
Statistics VI
30626 Accumulation of inter-
rupted curr. I7 (ΣI7:)
Statistics VI
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7UT6x, Manual 651
C53000-G1176-C230-5, Edition 09.2016
