Addr. Parameter Setting Options Default Setting Comments
244 SIDE 4 auto-connected
compensation
earth.electrode
compensation Side 4 is assigned to
251 AUX. CT IX1 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX1 is used as
252 AUX. CT IX2 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX2 is used as
253 AUX. CT IX3 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX3 is used as
254 AUX. CT IX4 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
Side 5 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
MeasLoc.5 earth
Not connected Auxiliary CT IX4 is used as
255 AUX CT IX3 TYPE 1A/5A input
sensitiv input
1A/5A input Type of auxiliary CT IX3
Functions
2.1 General
74 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
