No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
6975 dIEF: No. of detected
reverse pulses =
(No.reverse=)
Dir. Interm.
EF
VI * On
Off
On
Off
6976 dIEF: No. of detected
undefined pulses =
(No.undef.=)
Dir. Interm.
EF
VI * On
Off
On
Off
6979 dIEF: Alarm (dIEF ALARM) Dir. Interm.
EF
OUT * On
Off
On
Off
* LED BO
7551 50-1 InRush picked up
(50-1 InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 80 2 Yes
7552 50N-1 InRush picked up
(50N-1 InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 81 2 Yes
7553 51 InRush picked up (51
InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 82 2 Yes
7554 51N InRush picked up
(51N InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 83 2 Yes
7556 InRush OFF (InRush OFF) 50/51
Overcur.
OUT On
Of
f
* * LED BO 60 92 1 Yes
7557 InRush BLOCKED (InRush
BLK)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 93 1 Yes
7558 InRush Ground detected
(InRush Gnd Det)
50/51
Overcur.
OUT * On
Off
* LED BO 60 94 2 Yes
7559 67-1 InRush picked up
(67-1 InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 84 2 Yes
7560 67N-1 InRush picked up
(67N-1 InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 85 2 Yes
7561 67-TOC InRush picked up
(67-TOC InRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 86 2 Yes
7562 67N-TOC InRush picked
up (67N-TOCInRushPU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 87 2 Yes
7563 >BLOCK InRush (>BLOCK
InRush)
50/51
Overcur.
SP * * * LED BI BO
7564 Ground InRush picked up
(Gnd InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 88 2 Yes
7565 Phase A InRush picked up
(Ia InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 89 2 Yes
7566 Phase B InRush picked up
(Ib InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 90 2 Yes
7567 Phase C InRush picked up
(Ic InRush PU)
50/51
Overcur.
OUT * On
Off
* LED BO 60 91 2 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SJ62/64, Manual 703
C53000-G1140-C207-8, Edition 08.2016
