No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
6922 Interm. E/F prot. is
blocked (IEF blocked)
Intermit. EF OUT On
Of
f
On
Off
* LED BO 15
2
11 1 Yes
6923 Interm. E/F prot. is active
(IEF enabled)
Intermit. EF OUT On
Of
f
* * LED BO 15
2
12 1 Yes
6924 Interm. E/F detection
stage Iie> (IIE Fault det)
Intermit. EF OUT * * * LED BO
6925 Interm. E/F stab detection
(IIE stab.Flt)
Intermit. EF OUT * * * LED BO
6926 Interm.E/F det.stage Iie>
f.Flt. ev.Prot (IIE Flt.det
FE)
Intermit. EF OUT * On * 15
2
13 2 No
6927 Interm. E/F detected
(Intermitt.EF)
Intermit. EF OUT * On
Off
* LED BO 15
2
14 2 Yes
6928 Counter of det. times
elapsed (IEF Tsum exp.)
Intermit. EF OUT * On * LED BO 15
2
15 2 No
6929 Interm. E/F: reset time
running (IEF Tres run.)
Intermit. EF OUT * On
Off
* LED BO 15
2
16 2 Yes
6930 Interm. E/F: trip (IEF Trip) Intermit. EF OUT * On * LED BO 15
2
17 2 No
6931 Max RMS current value of
fault = (Iie/In=)
Intermit. EF VI ON
OFF
* 15
2
18 4 No
6932 No. of detections by stage
Iie>= (Nos.IIE=)
Intermit. EF VI ON
OFF
* 15
2
19 4 No
6951 >Block directional interm.
E/F prot. (>dIEF block)
Dir. Interm.
EF
SP On
Of
f
* * * LED BI BO
6961 Dir. Interm. E/F prot. is
switched off (dIEF OFF)
Dir. Interm.
EF
OUT On
Of
f
* * * LED BO
6962 Dir. Interm. E/F prot. is
blocked (dIEF blocked)
Dir. Interm.
EF
OUT On
Of
f
* * * LED BI BO
6963 Dir. Interm. E/F prot. is
active (dIEF active)
Dir. Interm.
EF
OUT On
Of
f
* * * LED BI BO
6972 dIEF: pick up (dIEF pick
up)
Dir. Interm.
EF
OUT * On
Off
On
Off
* LED BO
6973 dIEF: Trip (dIEF TRIP) Dir. Interm.
EF
OUT * On On
Off
* LED BO
6974 dIEF: No. of detected
forward pulses =
(No.forward=)
Dir. Interm.
EF
VI * On
Off
On
Off
Functions, Settings, Information
F.3 Information List
702 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
