No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
875 V1 (positive sequence) Voltage
Maximum (V1 Max =)
Min/Max meter - - - - - CD DD
876 Active Power Minimum (Pmin=) Min/Max meter - - - - - CD DD
877 Active Power Maximum (Pmax=) Min/Max meter - - - - - CD DD
878 Reactive Power Minimum (Qmin=) Min/Max meter - - - - - CD DD
879 Reactive Power Maximum
(Qmax=)
Min/Max meter - - - - - CD DD
880 Apparent Power Minimum
(Smin=)
Min/Max meter - - - - - CD DD
881 Apparent Power Maximum
(Smax=)
Min/Max meter - - - - - CD DD
882 Frequency Minimum (fmin=) Min/Max meter - - - - - CD DD
883 Frequency Maximum (fmax=) Min/Max meter - - - - - CD DD
884 Power Factor Maximum (PF Max=) Min/Max meter - - - - - CD DD
885 Power Factor Minimum (PF Min=) Min/Max meter - - - - - CD DD
888 Pulsed Energy Wp (active)
(Wp(puls))
Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive)
(Wq(puls))
Energy 133 56 No 205 - CFC CD DD
901 Power Factor (PF =) Measurement 134 137 No 9 14 CFC CD DD
924 Wp Forward (WpForward) Energy 133 51 No 205 - CFC CD DD
925 Wq Forward (WqForward) Energy 133 52 No 205 - CFC CD DD
928 Wp Reverse (WpReverse) Energy 133 53 No 205 - CFC CD DD
929 Wq Reverse (WqReverse) Energy 133 54 No 205 - CFC CD DD
963 I A demand (Ia dmd=) Demand meter - - - - - CFC CD DD
964 I B demand (Ib dmd=) Demand meter - - - - - CFC CD DD
965 I C demand (Ic dmd=) Demand meter - - - - - CFC CD DD
991 Pressure (Press =) Measurement - - - - - CFC CD DD
992 Temperature (Temp =) Measurement - - - - - CFC CD DD
996 Transducer 1 (Td1=) Measurement - - - - - CFC CD DD
997 Transducer 2 (Td2=) Measurement - - - - - CFC CD DD
1058 Overload Meter Max (Θ/
ΘTrpMax=)
Min/Max meter - - - - - CD DD
1059 Overload Meter Min (Θ/ΘTrpMin=) Min/Max meter - - - - - CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Measurement 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Measurement 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Measurement 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Measurement 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Measurement 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Measurement 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Measurement 134 146 No 9 7 CFC CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7SJ62/64, Manual 717
C53000-G1140-C207-8, Edition 08.2016
