Siemens SIPROTEC 4 User Manual

No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
1075 Temperature of RTD 8 (Θ RTD 8 =) Measurement 134 146 No 9 8 CFC CD DD
1076 Temperature of RTD 9 (Θ RTD 9 =) Measurement 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10
=)
Measurement 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11
=)
Measurement 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12
=)
Measurement 134 146 No 9 12 CFC CD DD
16004 Threshold Sum Current Exponen-
tiation (ΣI^x>)
SetPoint(Stat) - - - - - CFC CD DD
16009 Lower Threshold of CB Residual
Endurance (Resid.Endu. <)
SetPoint(Stat) - - - - - CFC CD DD
16017 Threshold Sum Squared Current
Integral (ΣI^2t>)
SetPoint(Stat) - - - - - CFC CD DD
16031 Angle between 3Vo and INsens.
(φ(3Vo,INs) =)
Measurement - - - - - CFC CD DD
16032 In2 (In2 =) Measurement - - - - - CFC CD DD
30701 Pa (active power, phase A) (Pa =) Measurement - - - - - CFC CD DD
30702 Pb (active power, phase B) (Pb =) Measurement - - - - - CFC CD DD
30703 Pc (active power, phase C) (Pc =) Measurement - - - - - CFC CD DD
30704 Qa (reactive power, phase A) (Qa
=)
Measurement - - - - - CFC CD DD
30705 Qb (reactive power, phase B) (Qb
=)
Measurement - - - - - CFC CD DD
30706 Qc (reactive power, phase C) (Qc
=)
Measurement - - - - - CFC CD DD
30707 Power Factor, phase A (PFa =) Measurement - - - - - CFC CD DD
30708 Power Factor, phase B (PFb =) Measurement - - - - - CFC CD DD
30709 Power Factor, phase C (PFc =) Measurement - - - - - CFC CD DD
30800 Voltage VX (VX =) Measurement - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
718 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
