Configuration
5-56 7SA6 Manual
C53000-G1176-C133-1
5.7 Date and Time Stamping
Integrated date and time stamping allows an exact evaluation of the sequence of
events (e.g. event logs and trip logs or limit violations). The following clock settings are
available:
• Internal RTC clock (R
eal Time Clock),
• External synchronization sources (DCF, IRIG B, SyncBox, IEC 60870-5-103),
• External minute impulses via binary input.
Time
Synchronization
Settings for time synchronization may be found in DIGSI
®
4 under 6HWWLQJV →
7LPHV\QFKURQL]DWLRQ (Figure 5-56).
Figure 5-56 Setting Window in DIGSI
®
4 – example
To open the 7LPH6\QFKURQL]DWLRQ)RUPDW window, the user should double-
click on 7LPH6\QFKURQL]DWLRQ. See Figure 5-57.
Note:
The device is delivered from the factory with the internal RTC clock selected as the
time source, independent of whether the device is equipped with a SCADA interface
or not.
