Siemens siprotec 7SA6 User Manual

Functions
6-154 7SA6 Manual
C53000-G1176-C133-1
6.9.4 Information Overview
2624 I> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2625 I> SOTF NO
YES
NO Instantaneous trip after Switch-
OnToFault
2640 Ip> 0.10..4.00 A; ∞ ∞ A Ip> Pickup
2642 T Ip Time Dial 0.05..3.00 sec; ∞ 0.50 sec T Ip Time Dial
2643 Time Dial TD Ip 0.50..15.00; ∞ 5.00 Time Dial TD Ip
2646 T Ip Add 0.00..30.00 sec 0.00 sec T Ip Additional Time Delay
2650 3I0p PICKUP 0.05..4.00 A; ∞ ∞ A 3I0p Pickup
2652 T 3I0p TimeDial 0.05..3.00 sec; ∞ 0.50 sec T 3I0p Time Dial
2653 TimeDial TD3I0p 0.50..15.00; ∞ 5.00 Time Dial TD 3I0p
2656 T 3I0p Add 0.00..30.00 sec 0.00 sec T 3I0p Additional Time Delay
2660 IEC Curve Normal Inverse
Very Inverse
Extremely Inverse
Long time inverse
Normal Inverse IEC Curve
2661 ANSI Curve Inverse
Short Inverse
Long Inverse
Moderately Inverse
Very Inverse
Extremely Inverse
Definite Inverse
Inverse ANSI Curve
2670 I(3I0)p Tele/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2671 I(3I0)p SOTF NO
YES
NO Instantaneous trip after Switch-
OnToFault
2630 Iph> STUB 0.10..25.00 A; ∞ 1.50 A Iph> STUB Pickup
2631 T Iph STUB 0.00..30.00 sec; ∞ 0.30 sec T Iph STUB Time delay
2632 3I0> STUB 0.05..25.00 A; ∞ 0.20 A 3I0> STUB Pickup
2633 T 3I0 STUB 0.00..30.00 sec; ∞ 2.00 sec T 3I0 STUB Time delay
2634 I-STUB Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2635 I-STUB SOTF NO
YES
NO Instantaneous trip after Switch-
OnToFault
Addr. Setting Title Setting Options Default Setting Comments
F.No. Alarm Comments
7104 >BLOCK O/C I>> >BLOCK Backup OverCurrent I>>
7105 >BLOCK O/C I> >BLOCK Backup OverCurrent I>
