Functions
6-637SA6 Manual
C53000-G1176-C133-1
Zone Z1B is usually used in combination with automatic reclosure and/or
teleprotection systems. It can be activated internally by the teleprotection functions
(see also section 6.4) or the integrated automatic reclosure (if available, see also
section 6.1) or externally by a binary input. It is generally set to at least 120% of the
line length. On three-terminal line applications (teed feeders), it must be set to
securely reach beyond the longest line section, even when there is additional infeed
via the tee-off point. The delay times are set in accordance with the type of application,
usually to zero or a very small delay. When used in conjunction with teleprotection
comparison systems, the dependence on the fault detection must be considered (refer
to margin heading “Distance Protection Prerequisites” in Sub-section 6.4.2.
If the distance protection is used in conjunction with an automatic recloser, it may be
determined in address VW$5!=% which distance zones are released prior
to a rapid automatic reclosure. Usually the overreaching zone Z1B is used for the first
cycle (VW$5!=% = <HV). This may be suppressed by changing the setting to
VW$5!=% equals 1R. In this case the overreaching zone Z1B is not released
before and during the 1
st
automatic reclose cycle. Zone Z1 is always released. The
setting only has an effect when the service condition of the automatic reclose function
is input to the device via binary input “!(QDEOH$5]RQHV” (FNo. 383, power system
data 2).
6.2.4.3 Settings
Note:
The indicated secondary values of impedance for setting ranges and default
settings refer to I
N
= 1 A. For the nominal current 5 A the values of impedance are to
be divided by 5.
Addr. Setting Title Setting Options Default Setting Comments
1301 Op. mode Z1 Forward
Reverse
Non-Directional
Inactive
Forward Operating mode Z1
1302 R(Z1) Ø-Ø 0.05..250.00 Ohm 1.25 Ohm R(Z1), Resistance for ph-ph-
faults
1303 X(Z1) 0.05..250.00 Ohm 2.50 Ohm X(Z1), Reactance
1304 RE(Z1) Ø-E 0.05..250.00 Ohm 2.50 Ohm RE(Z1), Resistance for ph-e
faults
1305 T1-1phase 0.00..30.00 sec; ∞ 0.00 sec T1-1phase, delay for single
phase faults
1306 T1-multi-phase 0.00..30.00 sec; ∞ 0.00 sec T1multi-ph, delay for multi phase
faults
1307 Zone Reduction 0..30 °; Ø 0 ° Zone Reduction Angle (load
compensation)
1351 Op. mode Z1B Forward
Reverse
Non-Directional
Inactive
Forward Operating mode Z1B (overr-
reach zone)
1352 R(Z1B) Ø-Ø 0.05..250.00 Ohm 1.50 Ohm R(Z1B), Resistance for ph-ph-
faults
1353 X(Z1B) 0.05..250.00 Ohm 3.00 Ohm X(Z1B), Reactance
