Technical Data
10-97SA6 Manual
C53000-G1176-C133-1
– Radiated electromagnetic interference 35 V/m; 25 MHz to 1000 MHz
ANSI/IEEE Std C37.90.2 amplitude and pulse modulated
– Damped oscillations 2.5 kV (peak value), polarity alternating
like IEC 60694, IEC 61000–4–12 100 kHz, 1 MHz, 10 MHz and 50 MHz,
R
i
= 200 Ω
EMC Tests; Inter-
ference Emission
(Type Tests)
Standard: EN 50081–* (Generic standard)
– Conducted interference, 150 kHz to 30 MHz
only power supply voltage limit class B
IEC–CISPR 22
– Radio interference field strength 30 MHz to 1000 MHz
IEC–CISPR 22 limit class B
10.1.6 Mechanical Stress Tests
Vibration and
Shock During
Operation
Standards: IEC 60255–21 and IEC 60068–2
– Vibration sinusoidal
IEC 60255–21–1, class 2 10 Hz to 60 Hz: ±0.075 mm amplitude
IEC 60068–2–6 60 Hz to 150 Hz: 1 g acceleration
frequency sweep rate 1 octave/min
20 cycles in 3 orthogonal axes.
– Shock half-sine shaped
IEC 60255–21–2, class 1 acceleration 5 g, duration 11 ms,
IEC 60068–2–27 3 shocks in each direction of
3 orthogonal axes
– Seismic vibration sinusoidal
IEC 60255–21–2, class 1 1 Hz to 8 Hz: ± 3.5 mm amplitude
IEC 60068–3–3 (horizontal axis)
1 Hz to 8 Hz: ± 1.5 mm amplitude
(vertical axis)
8 Hz to 35 Hz: 1 g acceleration
(horizontal axis)
8 Hz to 35 Hz: 0.5 g acceleration
(vertical axis)
Frequency sweep rate1 octave/min
1 cycle in 3 orthogonal axes
Vibration and
Shock During
Transport
Standards: IEC 60255–21 and IEC 60068–2
– Vibration sinusoidal
IEC 60255–21–1, class 2 5 Hz to 8 Hz: ±7.5 mm amplitude
IEC 60068–2–6 8 Hz to 150 Hz: 2 g acceleration
Frequency sweep rate1 octave/min
20 cycles in 3 orthogonal axes
– Shock half-sine shaped
IEC 60255–21–2, class 1 acceleration 15 g; duration 11 ms;
IEC 60068–2–27 3 shocks in each direction of
3 orthogonal axes
