Functions
6-74 7SA6 Manual
C53000-G1176-C133-1
The four possible programs may be set in address 362SPRGH, as described
in Sub-section 6.3.1: $OO]RQHVEORFN or ==%EORFNor =WR=EORFN
or ==%=EORFN.
Additionally the tripping function for unstable oscillations (out-of-step condition, loss of
system synchronism) can be set with parameter 3RZHU6ZLQJWULS (address ),
which should be set to <HV if required (presetting is 1R). In the event of power swing
tripping it is sensible to set 362SPRGH = $OO]RQHVEORFNfor the power swing
blocking, to avoid premature tripping by the distance protection.
6.3.3 Settings
6.3.4 Information Overview
Addr. Setting Title Function Setting Options Default Setting
2002 P/S Op. mode Power Swing all zones blocked
Z1/Z1B blocked
Z2 to Z5 blocked
Z1,Z1B,Z2 blocked
all zones blocked
2006 PowerSwing trip Power Swing NO
YES
NO
F.No. Alarm Comments
4164 Power Swing Power Swing detected
4166 Pow. Swing TRIP Power Swing TRIP command
4167 Pow. Swing L1 Power Swing detected in L1
4168 Pow. Swing L2 Power Swing detected in L2
4169 Pow. Swing L3 Power Swing detected in L3
