Functions
6-204 7SA6 Manual
C53000-G1176-C133-1
6.13.3 Settings
Addr. Setting Title Setting Options Default Setting Comments
3501 FCT Synchronism ON
OFF
ON Synchronism and Voltage Check
function
3502 Dead Volt. Thr. 1..60 V 5 V Voltage threshold dead line / bus
(ph-e)
3503 Live Volt. Thr. 20..125 V 90 V Voltage threshold live line / bus
(ph-e)
3504 Umax 20..140 V 110 V Maximum permissible voltage
3507 T-SYN. DURATION 0.01..600.00 sec; ∞ 1.00 sec Maximum duration of synchro-
nism-check
3508 T SYNC-STAB 0.00..30.00 sec; Ø 0.00 sec Synchronous condition stability
timer
3510 Op.mode with AR with consideration of CB
closing time
without consideration of CB
closing time
without considera-
tion of CB closing
time
Operating mode with AR
3511 Max. Volt. Diff 1.0..40.0 V 2.0 V Maximum voltage difference
3512 Max. Freq. Diff 0.03..2.00 Hz 0.10 Hz Maximum frequency difference
3513 Max. Angle Diff 2..60 ° 10 ° Maximum angle difference
3515A SYNC-CHECK YES
NO
YES Live bus / live line and Sync
before AR
3516 Usync> U-line< YES
NO
NO Live bus / dead line check before
AR
3517 Usync< U-line> YES
NO
NO Dead bus / live line check before
AR
3518 Usync< U-line< YES
NO
NO Dead bus / dead line check
before AR
3519 OVERRIDE YES
NO
NO Override of any check before AR
3530 Op.mode with MC with consideration of CB
closing time
without consideration of CB
closing time
without considera-
tion of CB closing
time
Operating mode with Man.Cl
3531 MC maxVolt.Diff 1.0..40.0 V 2.0 V Maximum voltage difference
3532 MC maxFreq.Diff 0.03..2.00 Hz 0.10 Hz Maximum frequency difference
3533 MC maxAngleDiff 2..60 ° 10 ° Maximum angle difference
3535A MC SYNCHR YES
NO
YES Live bus / live line and Sync
before MC
3536 MC Usyn> Uline< YES
NO
NO Live bus / dead line check before
Man.Cl
3537 MC Usyn< Uline> YES
NO
NO Dead bus / live line check before
Man.Cl
