Siemens siprotec 7SA6 User Manual

Functions
6-52 7SA6 Manual
C53000-G1176-C133-1
6.2.3.4 Information Overview
F.No. Alarm Comments
3603 >BLOCK Distance >BLOCK Distance protection
3611 >ENABLE Z1B >ENABLE Z1B (with setted Time Delay)
3613 >ENABLE Z1Binst >ENABLE Z1B instantanous (w/o T-Delay)
3617 >BLOCK Z4-Trip >BLOCK Z4-Trip
3618 >BLOCK Z5-Trip >BLOCK Z5-Trip
3651 Dist. OFF Distance is switched off
3652 Dist. BLOCK Distance is BLOCKED
3653 Dist. ACTIVE Distance is ACTIVE
3654 Dis.ErrorK0(Z1) Setting error K0(Z1) or Angle K0(Z1)
3655 DisErrorK0(>Z1) Setting error K0(>Z1) or Angle K0(>Z1)
3671 Dis. PICKUP Distance PICKED UP
3672 Dis.Pickup L1 Distance PICKUP L1
3673 Dis.Pickup L2 Distance PICKUP L2
3674 Dis.Pickup L3 Distance PICKUP L3
3675 Dis.Pickup E Distance PICKUP Earth
3681 Dis.Pickup 1pL1 Distance Pickup Phase L1 (only)
3682 Dis.Pickup L1E Distance Pickup L1E
3683 Dis.Pickup 1pL2 Distance Pickup Phase L2 (only)
3684 Dis.Pickup L2E Distance Pickup L2E
3685 Dis.Pickup L12 Distance Pickup L12
3686 Dis.Pickup L12E Distance Pickup L12E
3687 Dis.Pickup 1pL3 Distance Pickup Phase L3 (only)
3688 Dis.Pickup L3E Distance Pickup L3E
3689 Dis.Pickup L31 Distance Pickup L31
3690 Dis.Pickup L31E Distance Pickup L31E
3691 Dis.Pickup L23 Distance Pickup L23
3692 Dis.Pickup L23E Distance Pickup L23E
3693 Dis.Pickup L123 Distance Pickup L123
3694 Dis.Pickup123E Distance Pickup123E
3701 Dis.Loop L1-E f Distance Loop L1E selected forward
3702 Dis.Loop L2-E f Distance Loop L2E selected forward
3703 Dis.Loop L3-E f Distance Loop L3E selected forward
3704 Dis.Loop L1-2 f Distance Loop L12 selected forward
3705 Dis.Loop L2-3 f Distance Loop L23 selected forward
3706 Dis.Loop L3-1 f Distance Loop L31 selected forward
