Siemens siprotec 7SA6 User Manual

Technical Data
10-37SA6 Manual
C53000-G1176-C133-1
Permissible AC ripple voltage,
Peak to peak ≤15 % of nominal power supply
Power consumption
– quiescient approx. 5 W
– energized with 7SA610
∗–∗A/E/J approx. 8.6 W
with 7SA610
∗–∗B/F/K approx. 7.4 W
with 7SA6
∗1∗–∗A/E/J approx. 11.8 W
with 7SA6
∗1∗–∗B/F/K approx. 11.6 W
with 7SA6
∗2∗–∗A/E/J approx. 15.0 W
with 7SA6
∗2∗–∗B/K/F approx. 18.2 W
with 7SA6
∗2∗–∗C/G/L approx. 15.8 W
Bridging time for failure/short-circuit ≥50 ms at
U
NDC
= 48 V and U
NDC
≥ 110 V
of the power supply ≥20 ms at
U
NDC
= 24 V and U
NDC
= 60 V
Alternating Voltage Voltage supply via integrated AC/DC converter
Power consumption
– quiescient approx. 6.5 VA
– energized with 7SA610
∗–∗A/E/J approx. 13.6 VA
with 7SA610
∗–∗B/F/K approx. 12.4 VA
with 7SA6
∗1∗–∗A/E/J approx. 16.8 VA
with 7SA6
∗1∗–∗B/F/K approx. 16.6 VA
with 7SA6
∗2∗–∗A/E/J approx. 20.0 VA
with 7SA6
∗2∗–∗B/K/F approx. 23.2 VA
with 7SA6
∗2∗–∗C/G/L approx. 20.8 VA
Bridging time for failure/short-circuit ≥ 50 ms
of the power supply
10.1.3 Binary Inputs and Outputs
Binary Inputs Quantity
- 7SA610
∗–∗A/E/J 5 (allocatable)
- 7SA610
∗–∗B/F/K 7 (allocatable)
- 7SA61/31
∗–∗A/E/J 13(allocatable)
- 7SA61/31
∗–∗B/F/K 20(allocatable)
- 7SA61/32
∗–∗A/E/J 21(allocatable)
- 7SA61/32
∗–∗B/F/K 29(allocatable)
- 7SA61/32
∗–∗C/G/L 33(allocatable)
- 7SA641
∗–∗A/J 13(allocatable)
- 7SA641
∗–∗B/K 20(allocatable)
- 7SA642
∗–∗A/J 21(allocatable)
- 7SA642
∗–∗B/K 29(allocatable)
- 7SA642
∗–∗C/L 33(allocatable)
Nominal power supply alternating voltage U
NAC
115 VAC
Permissible voltage ranges 92 to 132 VAC
