Siemens siprotec 7SA6 User Manual

Functions
6-2177SA6 Manual
C53000-G1176-C133-1
6.14.3 Settings
Addr. Setting Title Setting Options Default Setting Comments
3701 Uph-e>(>) OFF
Alarm Only
ON
OFF Operating mode Uph-e overvolt-
age prot.
3702 Uph-e> 1.0..170.0 V 85.0 V Uph-e> Pickup
3703 T Uph-e> 0.00..30.00 sec; Ø 2.00 sec T Uph-e> Time Delay
3704 Uph-e>> 1.0..170.0 V 100.0 V Uph-e>> Pickup
3705 T Uph-e>> 0.00..30.00 sec; Ø 1.00 sec T Uph-e>> Time Delay
3709A Uph-e>(>) RESET 0.50..0.98 0.98 Uph-e>(>) Reset ratio
3711 Uph-ph>(>) OFF
Alarm Only
ON
OFF Operating mode Uph-ph over-
voltage prot.
3712 Uph-ph> 2.0..220.0 V 150.0 V Uph-ph> Pickup
3713 T Uph-ph> 0.00..30.00 sec; Ø 2.00 sec T Uph-ph> Time Delay
3714 Uph-ph>> 2.0..220.0 V 175.0 V Uph-ph>> Pickup
3715 T Uph-ph>> 0.00..30.00 sec; Ø 1.00 sec T Uph-ph>> Time Delay
3719A Uphph>(>) RESET 0.50..0.98 0.98 Uph-ph>(>) Reset ratio
3721 3U0>(>) (or Ux) OFF
Alarm Only
ON
OFF Operating mode 3U0 (or Ux)
overvoltage
3722 3U0> 1.0..220.0 V 30.0 V 3U0> Pickup (or Ux>)
3723 T 3U0> 0.00..30.00 sec; Ø 2.00 sec T 3U0> Time Delay (or T Ux>)
3724 3U0>> 1.0..220.0 V 50.0 V 3U0>> Pickup (or Ux>>)
3725 T 3U0>> 0.00..30.00 sec; Ø 1.00 sec T 3U0>> Time Delay (or T Ux>>)
3729A 3U0>(>) RESET 0.50..0.98 0.95 3U0>(>) Reset ratio (or Ux)
3731 U1>(>) OFF
Alarm Only
ON
OFF Operating mode U1 overvoltage
prot.
3732 U1> 2.0..220.0 V 150.0 V U1> Pickup
3733 T U1> 0.00..30.00 sec; Ø 2.00 sec T U1> Time Delay
3734 U1>> 2.0..220.0 V 175.0 V U1>> Pickup
3735 T U1>> 0.00..30.00 sec; Ø 1.00 sec T U1>> Time Delay
3739A U1>(>) RESET 0.50..0.98 0.98 U1>(>) Reset ratio
3741 U2>(>) OFF
Alarm Only
ON
OFF Operating mode U2 overvoltage
prot.
3742 U2> 2.0..220.0 V 30.0 V U2> Pickup
3743 T U2> 0.00..30.00 sec; Ø 2.00 sec T U2> Time Delay
3744 U2>> 2.0..220.0 V 50.0 V U2>> Pickup
