Functions
6-2657SA6 Manual
C53000-G1176-C133-1
6.19.3 Settings
Measurement
Supervision
Note:
The indicated secondary current values for setting ranges and default settings
refer to I
N
= 1 A. For the nominal current 5 A the current values are to be multiplied
by 5. The values of impedance are divided by 5.
Trip Circuit
Supervision
Addr. Setting Title Setting Options Default Setting Comments
2901 MEASURE.
SUPERV
ON
OFF
ON Measurement Supervision
2902A BALANCE U-LIMIT 10..100 V 50 V Voltage Threshold for Balance
Monitoring
2903A BAL. FACTOR U 0.58..0.95 0.75 Balance Factor for Voltage Mon-
itor
2904A BALANCE I LIMIT 0.10..1.00 A 0.50 A Current Balance Monitor
2905A BAL. FACTOR I 0.10..0.95 0.50 Balance Factor for Current Moni-
tor
2906A ΣI THRESHOLD 0.05..2.00 A 0.10 A Summated Current Monitoring
Threshold
2907A ΣI FACTOR 0.00..0.95; Ø 0.10 Summated Current Monitoring
Factor
2910 FUSE FAIL MON. ON
OFF
ON Fuse Failure Monitor
2911A FFM U>(min) 10..100 V 30 V Minimum Voltage Threshold U>
2912A FFM I< (max) 0.10..1.00 A 0.10 A Maximum Current Threshold I<
2913A FFM U<max (3ph) 2..100 V 5 V Maximum Voltage Threshold U<
(3phase)
2914A FFM Idelta (3p) 0.05..1.00 A 0.10 A Delta Current Threshold
(3phase)
2921 T mcb 0..30 ms; Ø 0 ms T mcb
Addr. Setting Title Function Setting Options Default Setting
4001 FCT TripSuperv. Trip Circuit Supervision ON
OFF
OFF
4002 No. of BI Trip Circuit Supervision 1..2 2
4003 Alarm Delay Trip Circuit Supervision 1..30 sec 2 sec
