Functions
6-1537SA6 Manual
C53000-G1176-C133-1
Stub Protection When using the I STUB protection the pick-up thresholds ,SK!678% (address )
and ,!678% (address ) are usually not critical, as this protection function is
only activated when the line isolator is open which implies that every measured current
should represents a fault current. With a 1
1
/
2
–circuit breaker arrangement similar to
Figure 6-85 it is possible that large short circuit currents flow from busbar A to busbar
B or to feeder 2 via the current transformers. These currents could cause different
transformation errors in the two current transformer sets I
A
and I
B
, especially in the
saturation range. The protection should therefore not be set unnecessarily sensitive.
If the minimum short circuit currents on the busbars are known, the pick-up threshold
,SK!678%is set somewhat (approx. 10 %) below the minimum two phase short
circuit current, ,!678% is set below the minimum single-phase current.
The time settings 7,SK678% (address ) and 7,678% (address ) are
set to 0 for this application, to ensure rapid clearance of a stub fault when the line
isolator is open.
If this stage is applied differently, similar considerations as for the other overcurrent
stages apply.
If the,6WXE-stage is to trip when switching the line on to a fault with or without a
short delay, 627)7LPH'(/$< (address , see above and refer to Sub-section
“General”), the parameter ,678%627) (address ) is set to <(6. If using the
stub protection, then set to 12 as the effect of this protection function only depends on
the position of the isolator.
6.9.3 Settings
Note:
The indicated secondary current values for setting ranges and default settings
refer to I
N
= 1 A. For the nominal current 5 A the current values are to be multiplied
by 5.
Addr. Setting Title Setting Options Default Setting Comments
2601 Operating Mode ON
Only Active with Loss of VT
sec. circuit
OFF
Only Active with
Loss of VT sec. cir-
cuit
Operating mode
2680 SOTF Time DELAY 0.00..30.00 sec 0.00 sec Trip time delay after SOTF
2610 Iph>> 0.10..25.00 A; ∞ 2.00 A Iph>> Pickup
2611 T Iph>> 0.00..30.00 sec; ∞ 0.30 sec T Iph>> Time delay
2612 3I0>> PICKUP 0.05..25.00 A; ∞ 0.50 A 3I0>> Pickup
2613 T 3I0>> 0.00..30.00 sec; ∞ 2.00 sec T 3I0>> Time delay
2614 I>> Telep/BI NO
YES
YES Instantaneous trip via Teleprot./
BI
2615 I>> SOTF NO
YES
NO Instantaneous trip after Switch-
OnToFault
2620 Iph> 0.10..25.00 A; ∞ 1.50 A Iph> Pickup
2621 T Iph> 0.00..30.00 sec; ∞ 0.50 sec T Iph> Time delay
2622 3I0> 0.05..25.00 A; ∞ 0.20 A 3I0> Pickup
2623 T 3I0> 0.00..30.00 sec; ∞ 2.00 sec T 3I0> Time delay
