7.4.5 Tagging
To identify unusual operating conditions in the power system, tagging can be done.
The tagging can, for example, be entered as additional operating conditions in
interlocking checks, which are set up with CFC. Tagging is configured in the same way
as for operating devices.
From PC with
DIGSI
®
4
With a device ready for operation, first press the key. The 0$,10(18 appears.
Using the key, select the menu item &RQWURO and move to editing the control
functions with the key. The selection &21752/ appears.
Select the item 7DJJLQJ with the key and switch to the next selection using the
key. The selection 7$**,1* appears. See Figure 7-54. The status of the tagging
is displayed 7DJJLQJ → 'LVSOD\, or changed using 7DJJLQJ → 6HW.
Figure 7-54 Tagging Equipment from the HMI
:
MENU
7$**,1*

'LVSOD\²!
6HW²!
&21752/

%UHDNHU6ZLWFK²!
7DJJLQJ²!
,QWHUORFN²!
0$,10(18

$QQXQFLDWLRQ²!
0HDVXUHPHQW²!
&RQWURO²!
Note:
The Manual Overwrite function is always done using the HMI on the SIPROTEC
®
4
devices.
