Siemens siprotec 7SA6 User Manual

Functions
6-218 7SA6 Manual
C53000-G1176-C133-1
6.14.4 Information Overview
3745 T U2>> 0.00..30.00 sec; Ø 1.00 sec T U2>> Time Delay
3749A U2>(>) RESET 0.50..0.98 0.98 U2>(>) Reset ratio
3751 Uph-e<(<) OFF
Alarm Only
ON
OFF Operating mode Uph-e under-
voltage prot.
3752 Uph-e< 1.0..100.0 V 30.0 V Uph-e< Pickup
3753 T Uph-e< 0.00..30.00 sec; Ø 2.00 sec T Uph-e< Time Delay
3754 Uph-e<< 1.0..100.0 V 10.0 V Uph-e<< Pickup
3755 T Uph-e<< 0.00..30.00 sec; Ø 1.00 sec T Uph-e<< Time Delay
3758 CURR.SUP. Uphe< ON
OFF
ON Current supervision (Uph-e)
3761 Uph-ph<(<) OFF
Alarm Only
ON
OFF Operating mode Uph-ph under-
voltage prot.
3762 Uph-ph< 1.0..175.0 V 50.0 V Uph-ph< Pickup
3763 T Uph-ph< 0.00..30.00 sec; Ø 2.00 sec T Uph-ph< Time Delay
3764 Uph-ph<< 1.0..175.0 V 17.0 V Uph-ph<< Pickup
3765 T Uphph<< 0.00..30.00 sec; Ø 1.00 sec T Uph-ph<< Time Delay
3768 CURR.SUP.Uphph< ON
OFF
ON Current supervision (Uph-ph)
3771 U1<(<) OFF
Alarm Only
ON
OFF Operating mode U1 undervolt-
age prot.
3772 U1< 1.0..100.0 V 30.0 V U1< Pickup
3773 T U1< 0.00..30.00 sec; Ø 2.00 sec T U1< Time Delay
3774 U1<< 1.0..100.0 V 10.0 V U1<< Pickup
3775 T U1<< 0.00..30.00 sec; Ø 1.00 sec T U1<< Time Delay
3778 CURR.SUP.U1< ON
OFF
ON Current supervision (U1)
F.No. Alarm Comments
10201 >Uph-e>(>) BLK >BLOCK Uph-e>(>) Overvolt. (phase-earth)
10202 >Uph-ph>(>) BLK >BLOCK Uph-ph>(>) Overvolt (phase-phase)
10203 >3U0>(>) BLK >BLOCK 3U0>(>) Overvolt. (zero sequence)
10204 >U1>(>) BLK >BLOCK U1>(>) Overvolt. (positive seq.)
10205 >U2>(>) BLK >BLOCK U2>(>) Overvolt. (negative seq.)
10206 >Uph-e<(<) BLK >BLOCK Uph-e<(<) Undervolt (phase-earth)
10207 >Uphph<(<) BLK >BLOCK Uphph<(<) Undervolt (phase-phase)
Addr. Setting Title Setting Options Default Setting Comments
