Siemens siprotec 7SA6 - Hardware and Connections

2-17SA6 Manual
C53000-G1176-C133-1
Hardware and Connections 2
This chapter describes the construction and connection of the 7SA6. The different
housing versions and available termination techniques are described.
The recommended and permitted data for the wiring is stated and suitable accessories
and tools are given.
2.1 Version of 7SA6 for Panel Flush Mounting (Cubicle Mounting) 2-2
2.2 Version of 7SA6 for Panel Surface Mounting 2-21
2.3 Version of 7SA6 with Detached Operator Panel 2-34
